MINIWARE TS101 Digital Display Electric Soldering Iron High Power Welding Pen Internal Heating Household Welding Repair Kits

• Soldering Tip Heating End

• Soldering Tip Connection End

• Anti-slip Cap

• Soldering Tip Insertion End

• Ball screw

• Button A (heating, temperature adjustment)

• Button B (setting, temperature adjustment)

• OLED Screen

• Ground Screw

• USB TYPE-C interface

• DC5525 interface

1)In standby mode, press B to enter setting mode;

2) ln setting mode, press A/B to select the seting item that needs to be modified, long press A to enter the modification statepress A/B to select the appropriate setting value and wait for 5 seconds after selection, the parameter is successfully modified and will automatically return to setting mode. Other settings can be modified in the same way;

3) After the setting is completed, long press B to save the modification and return to standby mode;

4)ln standby state, long press A, TS101 screen will display the current internal resistance of the soldering tip as “Tip R:xx”

5) ln standby state, long press B, TS101 screen will display the current firmware version as “Ver:V1.xx”.

Note: ln standby state, TS101 will enter the off screen state if it stay stil for a long time. You can wake it up by shaking thecontroller to enter standbv state
